Nokia M10 User’s Manual
DRAFT
E Copyright Nokia Telecommunications Oy NTC C33539002SE_A0 5-34
Command Show ADSL information
Description Displays the current status and some statistics about
the ADSL connection, e.g. upstream and downstream
data rates.
Syntax show dsl
Arguments None.
Example M10> show dsl
DSL Statistics:
Type: ADI DMT
Datapump HW Rev: 0
Datapump FW Rev: 2220ca05
Current Status: Operational
Init Status: Initialization successful
Last Init Status: Initialization success-
ful
Downstream Upstream
Current rate 7968000 bps 640000 bps
Maximum rate 10336000 bps 832000 bps
Fast parity bytes 0 0
Fast Codeword Size 1 1
Int Parity Bytes 10 8
Int Codeword Size 136 184
Interleve Depth 8 0
Near end
Error seconds 0
Noise Margin 7 db
Attenuation 17 db
Transmitted blocks 34814571
Received Blocks 34814433
Corrected Blocks 0
Uncorrected Blocks 0
M10>
