Management

DRAFT

NTC C33539002SE_A0

5-87

Pinhole settings

Pinhole settings are used to configure static entries to NAPT table. It
allows the configuring of servers, such as Web-HTTP servers, to LAN
which are visible via the WAN interface in cases where NAPT/address
mapping is enabled. The settings affect the whole system.

Note

If you have a Web server in LAN make sure that it has a
different port number than M10’s integral Web server.
You can change the M10’s Web server port through the
integral server settings.

Command

Configure pinhole

Description

Configures pinhole.

Syntax

set pinhole item [entry_number] external-port-start
[port_number] external-port-end [port_number] protocol
[tcp | udp | icmp | pptp] internal-ip [ip_address] internal-
port [port_number]

Arguments

The

entry_number

argument defines the unique pin-

hole entry number. The sequential values starting from
0 are accepted. The

external-port-start

spec-

ifies the start of the external port range. The

exter-

nal-port-end

specifies the end of the external port

range. Together the external port arguments define the
available range of allowed external ports. The

proto-

col

argument specifies the protocol. The

internal-

argument specifies the IP address of the server lo-

cated in LAN and the

internal-port

argument its

port. Valid values for

port_number

are 0 – 65535.

Example

m10> set pinhole item 1 external-port-
start 80 external-port-end 80 protocol
tcp internal-ip 192.168.1.180 internal-
port 80
