NI 5422 Specifications 6 ni.com
Figure 1. Normalized Passband Flatness, Direct Path
Figure 2. Normalized Passband Flatness, Low-Gain Amplifier Path
1 10 100
Frequency (MHz)
Flatness (dB)
0
–1
–2
–4
–3
1
Guaranteed Specification
Typical
+0.4 dB
–0.3 dB
–1.2 dB
–3.4 dB
+0.4 dB +0.4 dB +0.4 dB
–0.3 dB
1 10 100
Frequency (MHz)
Flatness (dB)
0
–1
–2
–4
–3
1
Guaranteed Specification
Typical
+0.3 dB
–0.5 dB
–3.4 dB
+0.7 dB +0.7 dB
–0.7 dB
+0.7 dB
–0.7 dB
