NI 5422 Specifications 16 ni.com
Sample Rate Range and Resolution
Sample Clock
Source
Sample Rate Range Sample Rate Resolution
—
Divide-by-N 5 MS/s to 200 MS/s Settable to (200 MS/s)/N
(1
≤ N ≤ 40)
High
Resolution 5 MS/s to 100 MS/s
>100 MS/s to 200 MS/s
1.06 µHz
4.24 µHz
CLK IN 5 MS/s to 200 MS/s Resolution determined by
external clock source.
External Sample Clock duty
cycle tolerance 40% to 60%.
DDC CLK IN 5 MS/s to 200 MS/s
PXI Star
Trigger 5 MS/s to 105 MS/s
PXI_Trig<0..7> 5 MS/s to 20 MS/s
Sample Clock Delay Range and Resolution
Sample Clock
Source Delay Adjustment
Range
Delay Adjustment
Resolution
—
Divide-by-N ±1 sample clock period <5 ps
High-
Resolution
≤100 MHz ±1 sample clock period Sample Clock
Period/16,384
High-
Resolution
>100 MHz ±1 sample clock period Sample Clock
Period/4,096
External (all) 0 ns to 7.6 ns <15 ps
Table 2. (Continued)
Specification Value Comments
