NI 5422 Specifications 4 ni.com
Maximum Output Voltage
Maximum
Output
Voltage Path Load Maximum Output Voltage (V) The combination
of Amplitude and
Offset is limited
by the Maximum
Output Voltage.
Direct 50
Ω
±0.500
1 k
Ω
±0.953
Open ±1.000
Low-
Gain
Amplifier
50
Ω
±1.000
1 k
Ω
±1.905
Open ±2.000
High-
Gain
Amplifier
50
Ω
±6.000
1 k
Ω
±11.43
Open ±12.00
Accuracy
DC Accuracy For the Low-Gain or High-Gain Amplifier Path:
±0.2% of Amplitude ± 0.05% of Offset ± 500 µV
(within ±10 °C of self-calibration temperature)
±0.4% of Amplitude ± 0.05% of Offset ± 1 mV
(0 °C to 55 °C)
All paths are
calibrated for
amplitude and
gain errors. The
Low-Gain and
High-Gain
Amplifier Paths
also are
calibrated for
offset errors.
Calibrated for
high impedance
load.
For the Direct Path:
Gain Accuracy: ±0.2% (within ±10 °C of self-calibration
temperature)
Gain Accuracy: ±0.4% (0 °C to 55 °C)
DC Offset Error: ±30 mV (0 °C to 55 °C)
AC Amplitude
Accuracy ±1.0% of desired Amplitude ± 1 mV 50 kHz sine
wave.
Output Characteristics
Output
Impedance 50
Ω nominal or 75 Ω nominal, software-selectable.
—
Output
Coupling DC —
Table 1. (Continued)
Specification Value Comments
