NI 5422 Specifications 28 ni.com
Loop Count 1 to 16,777,215.
Burst trigger: Unlimited —
Quantum Waveform size must be an integer multiple of four samples —
Memory Limits
8 MB
Standard
32 MB
Option 256 MB
Option
512 MB
Option
All trigger modes
except where
noted.
Arbitrary
Waveform
Mode,
Maximum
Waveform
Memory 4,194,176
Samples
16,777,088
Samples
134,217,600
Samples
268,435,328
Samples
Arbitrary
Sequence
Mode,
Maximum
Waveform
Memory 4,194,048
Samples
16,776,960
Samples
134,217,472
Samples
268,435,200
Samples
Condition: One
or two segments
in a sequence.
Arbitrary
Sequence
Mode,
Maximum
Waveforms 65,000
Burst
trigger:
8,000
262,000
Burst
trigger:
32,000
2,097,000
Burst
trigger:
262,000
4,194,000
Burst
trigger:
524,000
Condition: One
or two segments
in a sequence.
Arbitrary
Sequence
Mode,
Maximum
Segments in a
Sequence 104,000
Burst
trigger:
65,000
418,000
Burst
trigger:
262,000
3,354,000
Burst
trigger:
2,090,000
6,708,000
Burst
trigger:
4,180,000
Condition:
Waveform
memory is
<4,000 samples.
Table 10. (Continued)
Specification Value Comments
