Figure 30.

Measurements menu structure

DNT-fp measurements:

0 Display all
1 Noise margins
2 Rx levels
3 Tx levels
4 Attenuations
5 Supply voltage
6 Temperature

P
#
1:
2: xx xx xx xx *)
Line voltage xxV
Temperature xxC

7,0

Noise margins:
Pair 1 xx dB
Pair 2 xx dB *)

7,1

Rx levels:
Pair 1 xx dBm
Pair 2 xx dBm *)

7,2

Tx levels:
Pair 1 xx dBm
Pair 2 xx dBm *)

7,3

Supply voltage:
xxV

NM
dB
xx

At
dB
xx

Tx
dBm
xx

Rx
dBm
xx

NM = Noise margin
At = Attenuation
P = Pair

*) Not in T65690.01

Attenuations:
Pair 1 xx dB
Pair 2 xx dB *)

7,4

7,5

Temperature:
xxC

7,6
