Q1 menu diagrams

DN0445814

53 (60)

Issue 2-0 en

Nokia Proprietary and Confidential

Figure 27.

Settings menu structure (continued)

Test time out limit:
0 Display
1 to 64999 min
65000 no limit

6,1,7

Q1 via line:
0 Display
1 On
2 Off

6,1,3

Timing source:
0 Display
1 Internal
2 Line
3 Port
4 Transparent

6,2

Temperarure alarm limit:
0 Display
1 50C
2 55C
3 60C
4 65C
5 70C
6 75C
7 80C
8 85C
9 90C

6,1,12

Temperarure alarm severity:
0 Display
1 No alarm
2 A-level alarm
3 B-level alarm

6,1,13

6,3
6,4
6,7
