© National Instruments Corporation B-1 NI PXI-1056 User Manual
B
Pinouts
This appendix describes the P1 and P2 connector pinouts for the PXI-1056
backplane.
Table B-1 shows the P1 (J1) connector pinout for the System
Controller slot.
Table B-2 shows the P2 (J2) connector pinout for the System
Controller slot.
Table B-3 shows the P1 (J1) connector pinout for the star trigger slot.
Table B-4 shows the P2 (J2) connector pinout for the star trigger slot.
Table B-5 shows the P1 (J1) connector pinout for the peripheral slots.
Table B-6 shows the P2 (J2) connector pinout for the peripheral slots.
Note PXI signals are shown in bold.
For more detailed information, refer to the PXI Hardware Specification,
Revision 2.1. Contact the PXI Systems Alliance for a copy of the
specification or visit
www.pxisa.org .
