Chapter 2

Installation and Configuration

NI PXI-1056 User Manual

2-14

ni.com

Help Menu Requests

Note

This is not available on older SMM code versions.

PXI System Configuration with MAX

Configuration of the PXI system is handled through Measurement &
Automation Explorer (MAX), included on the NI Driver CD-ROM
packaged with your kit. MAX creates the

pxisys.ini

file which defines

the layout and parameters of your PXI system. After installing the software
on the NI Driver CD-ROM, the MAX icon will be present on the desktop.
The configuration steps for single- or multiple-chassis systems are the
same.

Command

Response

?

Commands are 2 letters in length as follows:

VA - Report the 4 voltages defined as

–V1 = +3.3 VDC

–V2 = +5 VDC

–V3 = +12 VDC

–V4 = –12 VDC

FA - Report the 3 Fan speeds

SA - All status

TA - Report the 3 temperature sensors
