Figure 1-2. Rear View of the PXI-1056 Chassis

Optional Equipment

Contact National Instruments to order the following options for the
PXI-1056 chassis.

EMC Filler Panels

Optional EMC filler panel kits are available from National Instruments.

Rear Rack Mount Kits

A rear rack mount kit option is available for mounting the PXI-1056 chassis
into a 19 in. instrument cabinet.

1

Fan Filter Cover

2

Power Supply Shuttle Retainer Screws (x4)

3

Power Supply Shuttle Handles (x2)

4

Chassis Ground Screw

5

Circuit Breaker

6

Universal AC Inlet

7

Fan Speed Selector Switch

8

RS-232 Connector for Remote
Voltage/Temperature/Fan Monitoring

1

7

8

6

4

5

3

3

2

2

2

2
