National Instruments NI CardBus-8310-to-PXI Expansion User Manual
Page 14
Chapter 1
Introduction
© National Instruments Corporation
1-7
NI CardBus-8310-to-PXI Expansion User Manual
Figure 1-2. Front Panel of the NI PXI-8310 Expansion Card
1
L0 Link Status LEDs (0–3)
2
Receiver Ports (RX)
3
L1 Link Status LEDs (0–3)
4
Transmitter Ports (TX)
3
2
1
4
NI PXI-8310
PXI StarFabric
©
Interface
