Active Archive Appliance (A3) v6.5
PowerFile Confidential
Racking and Installation Guide
6
Installing the Cache Expansion Unit
In This Chapter
•
Identifying the Rail Kit Components
•
•
Attaching the Mounting Brackets and Rails
•
This chapter provides instructions for installing the Cache Expansion Unit in the rack. Up to two
Cache Expansion Units can be installed per one Archive Engine.
Note: The following installation procedures apply to standard Electronics Industries Association (EIA)
racks. Non-EIA racks may not be able to support the Cache Expansion Unit. If you are using a non-EIA
rack, PowerFile recommends that you secure the Cache Expansion Unit using slide rails, which are
available from PowerFile Authorized Resellers.
