Page 36: Battery
MIC/AUDIO
Item
Setting
options
Remarks
FRONT MIC
POWER
ON
OFF
ON: Phantom power is supplied to the
front microphone.
OFF: Phantom power is not supplied to the
front microphone.
FRONT MIC
–40dB
–50dB
–60dB
For selecting the camera mic input level.
REAR MIC CH2
–40dB
–50dB
–60dB
For setting the input mic level for the rear
jack AUDIO CH2 input.
MIC LOWCUT CH1
ON
OFF
ON: The low-cut filter is set to ON for the
CH1 mic input.
OFF: The low-cut filter is set to OFF for the
CH1 mic input.
MIC LOWCUT CH2
ON
OFF
ON: The low-cut filter is set to ON for the
CH2 mic input.
OFF: The low-cut filter is set to OFF for the
CH2 mic input.
REAR MIC CH1
–40dB
–50dB
–60dB
For setting the input mic level for the rear
jack AUDIO CH1 input.
“
” indicates the factory setting.
36
BATTERY
Item
Setting
options
Remarks
BATTERY SELECT
NiCd12
NiCd13
NiCd14
TYPE A
TYPE B
ANTON-D
IDX-D
For selecting the type of battery used.
NiCd12:
NP-1B made by Sony
NiCd13:
TRIM13 made by Anton Bauer
NiCd14:
TRIM14 made by Anton Bauer
TYPE A:
13.2 V NiMH type
TYPE B:
Digital 14 V (Hitron 100) made
by Anton Bauer
ANTON-D: Digital battery made by Anton
Bauer
IDX-D:
Digital battery made by IDX
TYPE B END
11.0V
:
12.5V
:
15.0V
For designating type B voltage. When the
voltage drops below the level set here, the
battery is considered to be flat, and a
warning is displayed. A voltage from 11.0
V to 15.0 V is used as the setting.
TYPE A NEAR
END
11.0V
:
11.6V
:
15.0V
For designating type A voltage. When the
voltage drops below the level set here, the
battery is considered to have a minimal
remaining charge, and a warning is
displayed. A voltage from 11.0 V to 15.0 V
is used as the setting.
TYPE B NEAR
END
11.0V
:
13.0V
:
15.0V
For designating type B voltage. When the
voltage drops below the level set here, the
battery is considered to have a minimal
remaining charge, and a warning is
displayed. A voltage from 11.0 V to 15.0 V
is used as the setting.
TYPE A END
11.0V
:
11.2V
:
15.0V
For designating type A voltage. When the
voltage drops below the level set here, the
battery is considered to be flat, and a
warning is displayed. A voltage from 11.0
V to 15.0 V is used as the setting.
Menu contents
MAIN menu 1 of 2 (main menu)
ANTON-D END
11.0V
:
13.8V
:
15.0V
For designating the voltage of the ANTON-
D digital battery. When the voltage drops
below the level set here, the battery is
considered to be flat, and a warning is
displayed. A voltage from 11.0 V to 15.0 V
is used as the setting.
IDX-D NEAR END
11.0V
:
12.8V
:
15.0V
For designating the voltage of the IDX-D
digital battery. When the voltage drops
below the level set here, the battery is
considered to have a minimal remaining
charge, and a warning is displayed. A
voltage from 11.0 V to 15.0 V is used as the
setting.
ANTON-D NEAR
END
11.0V
:
14.1V
:
15.0V
For designating the voltage of the ANTON-
D digital battery. When the voltage drops
below the level set here, the battery is
considered to have a minimal remaining
charge, and a warning is displayed. A
voltage from 11.0 V to 15.0 V is used as the
setting.
IDX-D END
11.0V
:
12.0V
:
15.0V
For designating the voltage of the IDX-D
digital battery. When the voltage drops
below the level set here, the battery is
considered to be flat, and a warning is
displayed. A voltage from 11.0 V to 15.0 V
is used as the setting.
CUE REC SEL
CH1
MIX
CH2
For selecting the signal to be recorded on
the CUE track.
CH1: The CH1 input signal is recorded.
MIX: The CH1 and CH2 input signals are
mixed and recorded.
CH2: The CH2 input signal is recorded.
LINE CH1/CH2
+4dB
0dB
–6dB
For selecting the line input level of the
signals to be supplied to the AUDIO CH1
and CH2 rear jacks.
REAR SEL CH1
XLR
WIRELESS
For selecting the CH1 rear input.
XLR:
The input from the XLR
connector is selected.
WIRELESS: The input from the wireless
receiver is selected.
MIC levels cannot be selected.
REAR SEL CH2
XLR
WIRELESS
For selecting the CH2 rear input.
XLR:
The input from the XLR
connector is selected.
WIRELESS: The input from the wireless
receiver is selected.
MIC levels cannot be selected.
LIMITER CH1
OFF
ON
For switching the CH1 AUDIO limiter ON or
OFF. This item’s setting is functional only
when MANU has been selected as the
AUDIO SELECT setting.
OFF: The limiter is OFF.
ON: The limiter is ON.
LIMITER CH2
OFF
ON
For switching the CH2 AUDIO limiter ON or
OFF. This item’s setting is functional only
when MANU has been selected as the
AUDIO SELECT setting.
OFF: The limiter is OFF.
ON: The limiter is ON.
