OPERATION
POWER-UP DISPLAY
When the system is powered up, the selected protocol, revision number, and other information is displayed on the monitor. For example,
the screen might show the following information:
The information displayed depends on the selected protocol (C, D, or P) and the menu selection for power-
up mode. (Refer to the
Power-Up Mode in the Programming section).
The information remains on the monitor until the system is moved.
HOW TO OPERATE YOUR SYSTEM
Operation How to Control
Pan and Tilt Move joystick left/right and up/down.
Scanning
Stop scan Call preset 96.
Random scan Call preset 97.
Frame scan Call preset 98.
Auto scan Call preset 99.
Zoom Far To zoom far, do the following:
1. Press the Zoom Tele button or turn the joystick clockwise until zoom stops at the optical zoom
1 limit.
2. Release the button or joystick.
3. To continuing zooming (digitally), immediately press the button or turn the joystick clockwise again until you
have the picture you want or reach the digital zoom 2 limit.
Zoom Wide Press the Zoom Wide button or turn the joystick counterclockwise.
Presets Refer to the documentation supplied with the controller.
Patterns Refer to the documentation supplied with the controller.
1 Optical zoom magnifies the image and the picture remains clear. Resolution is constant.
2 Digital zoom magnifies the image and the picture may appear pixilated. The larger the zoom limit the greater the reduction in resolution.
ESPRIT 16X IOP 1.0h
CONFIGURE DONE
D Address 1
P Address 2
Comm 2400, N, 8, 1
CAMERA XXXX-XXXX
