Pelco ESPRIT ES30C - Manual (Page 30)

30 C309M-J (9/04)
LOWLIGHT LIMIT (MODELS ES30C22/ES31C22 AND ES30CBW18/ES31CBW18 ONLY)
This setting determines the maximum length of time the shutter will remain open automatically in low light conditions. There are six
choices:
2 = 1/2 second 8 = 1/8 second 30 = 1/30 second
4 = 1/4 second 15 = 1/15 second 60 = 1/60 second
NOTE: LOWLIGHT does not mean NO LIGHT. Some type of illumination is required.
NOTE: Auto focus is automatically turned off when the shutter speed is longer than 1/8 of a second.
To change the LowLight setting:
1. On the main menu, move the joystick up or down to position the cursor (>) beside Camera.
2. Press the Iris Open button to enter the Camera menu.
3. Position the cursor (>) beside Next.
4. Press the Iris Open button to go to the Next (camera) menu.
5. Position the cursor (>) beside LowLight Limit.
6. Press the Iris Open button. The cursor moves to the right, beside the current LowLight Limit.
7. Move the joystick up or down to choose the LowLight Limit.
8. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
Exit
MAIN MENU
Backlight comp Off
Zoom limit x- -
Reset camera
Next
Exit
Camera Menu
LowLight limit
Shutter speed
Auto
Auto focus mode Auto
Prev
Exit
Next Menu
