C309M-J (9/04) 43
ZOOM
Zoom programs the horizontal display position of the Zoom label. The following settings are available for the Zoom label:
Off – Label is not displayed.
Left – Label is displayed on the left-hand side of the screen.
Center (default) – Label is displayed in the center of the screen.
Right – Label is displayed on the right-hand side of the screen.
NOTE: Zoom display is not available while you are programming or running a pattern.
To program the horizontal label position for Zoom:
1. Program preset 95 (28). The main menu appears.
2. Position the cursor (>) beside Other.
3. Press the Iris Open button to enter the Other menu.
4. Position the cursor (>) beside Az/El/Direction.
5. Press the Iris Open button to enter the Az/El/Direction menu.
6. Position the cursor (>) beside Zoom.
7. Press the Iris Open button. The cursor moves to the right.
8. Move the joystick up or down to view the available selections.
9. SELECT – Press the Iris Open button to make a selection.
CANCEL – Press the Iris Close button to cancel a selection.
Exit
MAIN MENU
Proportional pan On
Park time minutes 0
Scan Speed deg/s 25
Pattern Length 1.5 min
Spd Profile
Exit
Other Menu
Set Azimuth Zero
Az/El
Az/El Line
Direction
Direction Line
Zoom
Zoom Line
Disp Duration
Exit
Az/El/Direction
