38 C309M-J (9/04)
SHUTTER SPEED
There are several electronic shutter speed settings:
Auto
1/2
1/4
1/8
1/15
1/30
1/60
1/120
1/180
1/250
1/500
1/1000
1/2000
1/4000
1/10,000
1/30,000
In the Auto setting the camera controls the shutter speed automatically. Increasing the shutter speed lowers the light sensitivity, but
rapidly moving objects will be less blurred.
NOTE: (ES30PCBW18/ES31PCBW18) If the IR Filter Mode is set to Auto, the Shutter Speed setting will default automatically to the
Auto setting.
To change the electronic shutter speed settings:
1. Program preset 95 (28). The main menu appears.
2. Position the cursor (>) beside Camera.
3. Press the Iris Open button to enter the Camera menu.
4. Position the cursor (>) beside Next.
5. Press the Iris Open button to go to the Next menu.
6. Position the cursor (>) beside Shutter Speed.
7. Press the Iris Open button.
8. The cursor moves to the right, beside the current shutter speed.
9. Move the joystick up or down to choose the shutter speed.
10. SELECT – Press the Iris Open button on your keyboard to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
Exit
MAIN MENU
Backlight comp Off
Zoom limit x- -
Reset camera
Next
Exit
Camera Menu
LowLight limit
Shutter speed
Auto
Auto focus mode Auto
Prev
Exit
Next Menu
