46 C309M-J (9/04)
SPECIFICATIONS
ELECTRICAL
Input Voltage:
24, 120, or 230 VAC, 50/60 Hz; switch selectable for 120/230 VAC inputs. Reset feature enabled
when power becomes unstable or interrupted.
Power Requirements: Maximum power consumption is 70 VA per system
Heater and Defroster: Thermostatically controlled heater consumes 10 watts and cycles on at 40
°
F (5
°
C) and off at 60
°
F
(16
°
C)
Defogger: The window defogger consumes 3 watts and cycles on at 70
°
F (21
°
C) and off at 85
°
F (29
°
C)
Electrical Connections: Two power source connections made at mount location with wire splices and one ground wire
splice; one BNC receptacle and four wire splices at mount location for RS-422 D and P protocols;
two wire splices for open collector auxiliary output
Aux 2: Open collector output with 2-second activation; connected relay must require no more than 32 VDC
and 40 mA to energize relay coil; wire length between Esprit and relay must be less than 100 ft (30 m)
MECHANICAL
Construction
System: Die-cast, extruded and sheet aluminum; stainless steel hardware
EWM Wall Mount: Aluminum
EPA Pedestal Adapter: Aluminum
Finish
System: Gray polyester powder coat, anodized
EWM Wall Mount: Gray polyester powder coat
EPA Pedestal Adapter: Gray polyester powder coat
Viewing Window: 0.23-inch (5.84 mm) thick, optically clear, polycarbonate with proprietary impact resistant UV rated
coating
Window Viewing Area: 2-inch (5 cm) diameter
CAMERAS
Scanning System
ES30C16/ES31C16 and
ES30C22/ES31C22:
2:1 interlace
ES30CBW18/ES31CBW18: 2:1 interlace
Image Sensor: 1/4-inch
Effective Pixels
ES30C16/ES31C16 NTSC: 768 (H) x 494 (V)
ES30C16/ES31C16 PAL: 752 (H) x 582 (V)
ES30C22/ES31C22 NTSC: 768 (H) x 494 (V)
ES30C22/ES31C22 PAL: 752 (H) x 582 (V)
ES30CBW18/ES31CBW18 NTSC: 724 (H) x 494 (V)
ES30CBW18/ES31CBW18 PAL: 724 (H) x 582 (V)
Horizontal Resolution
ES30C16/ES31C16: >470 TV lines (NTSC) >460 TV lines (PAL)
ES30C22/ES31C22: >470 TV lines (NTSC) >460 TV lines (PAL)
ES30CBW18/ES31CBW18: >470 TV lines (NTSC) >470 TV lines (PAL)
Focal Length
ES30C16/ES31C16: 4 mm to 64 mm optical
ES30C22/ES31C22: 4 mm to 88 mm optical
ES30CBW18/ES31CBW18: 3.6 mm to 82.8 mm optical
Zoom Ratio
ES30C16/ES31C16: 16X optical zoom, 10X electronic zoom
ES30C22/ES31C22: 22X optical zoom, 10X electronic zoom
ES30CBW18/ES31CBW18: 23X optical zoom, 10X electronic zoom
Digital Slow Shutter: Auto/manual speed selection
Horizontal Angle of View
ES30C16/ES31C16: 43
°
at 4 mm wide zoom; 3
°
at 64 mm telephoto zoom
ES30C22/ES31C22: 47
°
at 4 mm wide zoom; 2
°
at 88 mm telephoto zoom
ES30CBW18/ES31CBW18: 54
°
at 3.6 mm wide zoom; 2.5
°
at 82.8 mm telephoto zoom
Focus: Automatic and manual override
