Polaris ATP 330 4x4 - Manual (Page 102)

99
MAINTENANCE AND LUBRICATION
Adjustments
WARNING
Improperly installed wheels can adversely affect tire wear and
vehicle handling, which can result in serious injury or death.
Always ensure that all nuts are torqued to specification. Do not
service axle nuts that have a cotter pin installed. See your
Polaris dealer.
Wheel Installation
1. Place the transmission in
park and lock the parking
brake.
2. Place the wheel on the
wheel hub with the valve
stem toward the outside
and rotation arrows on the
tire pointing toward
forward rotation.
3. Install the wheel nuts and finger
tighten.
4. Lower the vehicle to the ground.
5. Torque the nuts to specification.
Wheel Nut Torque Specifications
Check the wheel nut torques occasionally and when they’ve been
loosened for maintenance service.
Location Specification
Front Wheel Nuts 27 ft. lbs. (37 Nm)
Rear Wheel Nuts 27 ft. lbs. (37 Nm)
