Chapter 3
Removing the USB Board
1. See “Removing the Upper Cover” on page 76.
2. Disconnect the USB Board cable from the Mainboard connector.
3. Lift the USB cable away from Lower Cover to detach the adhesive.
4. Remove the single screw securing the USB Board to the Lower Cover.
Step
Size
Quantity
Screw Type
USB Board
M2.5*5
1
