122 Chapter 3
Replacing the TouchPad Bracket
Replacing the Upper Cover
1. Replace the TouchPad Bracket bottom edge first to
engage the securing clips (1). Rotate the bracket
on to the Upper Cover and press down as
indicated (2).
2. Secure the bracket to the Upper Cover with a single
screw.
3. Insert the TouchPad FFC in to the connector as
shown.
4. Close the FFC locking latch to secure the cable in
place.
1. Place the upper cover on the lower cover front edge first and lower the cover into position.
(1)
(2)
