Chapter 3
Removing the Power Board
1. See “Removing the LCD Panel” on page 99.
2. Remove the single screw securing the Power Board Bracket to the LCD Module.
3. Lift the Power Board Bracket from the LCD Panel as shown.
4. Remove the Power Board from the bracket as shown.
Step
Size
Quantity
Screw Type
Power Board
M2*3
1
