GRT-504 4-Wire G.SHDSL.bis Firewall Router User’s Manual
The flow chart of bridge mode setup:
Setup up system mode and SHDSL mode
Click Bridge and CPE Side to setup Bridging mode and then click Next for the next setting.
This router can be setup as one of two SHDSL.bis working mode: CO (Central Office) and CPE
(Customer Premises Equipment). For connection with DSLAM, the SHDSL.bis router working
mode is CPE. For “LAN to LAN” connection, one side must be CO and the other side must be
CPE.
Set up (a) LAN IP address , Subnet Mask, Gateway and Host Name
(b) WAN1 VPI,VCI and Encapsulation
33
