GRT-504 4-Wire G.SHDSL.bis Firewall Router User’s Manual
----------------------------------------------------------------------
Command: setup ip_share pat modify <1~10>
Message: Please input the following information.
Virtual server entry number <1~10>: 1
----------------------------------------------------------------------
After key in enter, the screen will prompt as below.
>> interface
Active interface
port TCP/UDP port number
server Host IP address and port number
protocol Transport protocol
name Service name
begin The schedule of beginning time
end The schedule of ending time
Set the active interface number via interface command.
You can configure the global port number by using port command.
The local server, host, IP address, and port number are configured via server command.
The authorized access protocol is setup via protocol command.
Name command can be used to configure the service name of the host server.
Begin and end command is used to setup the local server schedule to access.
You can view the fixed NAT mapping entry via list command.
7.12.10.3 DMZ
DMZ (demilitarized zone) is a computer host or small network inserted as a “neutral zone”
between a company private network and the outside public network. It prevents outside users from
getting direct access to a server that has company private data.
To setup demilitarized zone, move the cursor “>>” to dmz and press enter.
>> active
Trigger DMZ host function
address Configure virtual IP address and interface
You can enable the demilitarized zone via active command.
After enabling the DMZ, shift the cursor to address and press enter.
----------------------------------------------------------------------
Command: setup ip_share dmz address <1~10>
Message: Please input the following information.
Virtual IP address: 192.168.0.251
Active interface number (Enter for default) <1>: 1
