ENGLISH
PE1500 User’s Manual
23
Video Modes
Your LCD monitor supports the following industry-standard combinations of screen resolution
and refresh rates. Other combinations are possible, but may require adjustments to the image.
For optimum performance, set your PC to a screen resolution of 1024 x 768 at a 60 Hz refresh
rate.
Supported Resolution
(dots x lines)
Vertical Frequency
(Refresh Rate)
VGA 640 x 350
640 x 480
640 x 480
640 x 480
640 x 480 70 Hz
60 Hz
70 Hz
72 Hz
75 Hz
SVGA 800 x 600
800 x 600
800 x 600
800 x 600
800 x 600 56 Hz
60 Hz
70 Hz
72 Hz
75 Hz
XGA 1024 x 768
1024 x 768
1024 x 768
1024 x 768 60 Hz
70 Hz
72 Hz
75 Hz
US TEXT 720 x 400 70 Hz
Power MAC 640 x 480
832 x 624 67 Hz
75 Hz
Note: The display is capable of going beyond these recommended modes.
Unknown Video Modes
Like all other monitors, your LCD monitor is designed to work with standard video modes.
However, not all video/graphic cards use only standard display modes.
Your LCD monitor uses state-of-the-art technology, which is designed to synchronize to any
display mode. We recommend choosing one of the supported modes listed above. If you choose
an unknown mode, you will need to manually adjust the clock, phase, and image position.
If you must use an unknown mode, you can run Auto Setup at first. If Auto Setup doesn’t provide
adequate image adjustment, then you must manually adjust the clock, phase, horizontal position,
and vertical position.
