Page 96: 1. pd8130/pd8150 dimensions, Prel imina ry
82
Planar PD8130/PD8150 Installation/Operation Manual
PREL
IMINA
RY
7.2
PD8130/PD8150
Dimensions
Figure 7-1 shows the PD8130/PD8150 dimensions, in millimeters.
Figure 7-1. PD8130/PD8150 Dimensions
150
160
CEILING MOUNT HOLES
M4 x 4
75
135
530
200
455
80
LENS CENTER LINE
APPROXIMATE CENTER
OF GRAVITY
