Planar PD8130/PD8150 Installation/Operation Manual
11
PREL
IMINA
RY
2.3
PD8130/PD8150 Remote
Control
Figure 2-4 shows the PD8130/PD8150 remote control, and the paragraphs that
follow describe its functionality.
Figure 2-4. PD8130/PD8150 Remote Control
1. ON
Use this button to turn the projector on.
2. OFF
Use this button to turn the projector off.
3. Source Selection Buttons (1-5):
Press to select a video source. By default, these buttons are assigned as
follows: 1 = HDMI 1; 2 = HDMI 2; 3 = Component 1; 4 = S-Video; 5 = Video.
However, you can assign each button to any source you wish.
ON
l
POWER
OFF
1
4
2
3
5
M1
GAMMA
PIP
M2
OS
SWAP
M3
SHARP
NR
LIGHT
▲
▼
▲
▼
ENTER
MENU
USER MEMORY
SOURCE
9
1
4
2
3
5
7
6
8
10
