Connecting Source
Components to the
PD8130/PD8150
Connect your video sources to the PD8130/PD8150 as shown and described in
the sections that follow.
HDMI/DVI Connections: See Figure 3-7.
Figure 3-7. HDMI/DVI Source Connections
Use the HDMI inputs whenever possible. This ensures the
highest video quality because the signal is carried in the
digital domain throughout the entire signal path, from source
component output into the projector.
Tip
HDMI or DVI Source(s)
(BD/HD-DVD/DVD Player,
HD Set Top Box,
Game Console etc.)
