Page 39: Prel imina ry
Planar PD8130/PD8150 Installation/Operation Manual
25
PREL
IMINA
RY
Component Video Connections: Connect your component video sources to
the COMPONENT 1/SCART, COMPONENT 2 (PD8150 only) or RGB inputs as shown
in Figure 3-9.
Figure 3-9. Component Video Connections
Y Pb Pr
Y Pb Pr
DTV Set-Top Box or
Other Component
(YPbPr) Source
