Philips indoor luminaires 11.12
Occuswitch
Lighting Controls
easy installation and mounting of
Occuswitch in the ceiling. A separate
Wieland cable is available for easy, fast
and trouble-free installationOccuswitch
basic version. LRM1070 is a movement
detector with a built-in switch. It
switches the lights off in a room or
area when it is vacated, thus saving up
to 30% on electricity consumption. Occuswitch can switch any load up
to 6 A and control an office area of
around 20 m². A detachable mains
connector enables easy installation
and mounting of Occuswitch in the
ceiling. A separate Wieland cable is
available for easy, fast and trouble-free
installation Product ID EOC
LRM1070/00 SENSR MOV DET ST 731384 99
Ш 80
Ш 95
50
LRM1070/1080
enables easy installation and mounting
of Occuswitch in the ceiling. A separate
Wieland cable is available for easy, fast
and trouble-free installation. Same
as the LRM1070 but with parallel
operation (up to 10 Occuswitches),
local override and absence
modeOccuswitch advanced version.
LRM1080 is a movement detector with a built-in switch. It switches the
lights off in a room or area when it
is vacated, thus saving up to 30% on
electricity consumption. Occuswitch
can switch any load up to 6 A and
control an office area of around 20
m². A detachable mains connector
enables easy installation and mounting
of Occuswitch in the ceiling. A separate
Product ID EOC
LRM1080/00 SENSR MOV DET
ST IR
731407 99
Ceiling box for surface mounting of
Occuswitch (LRM1070, LRM1080)
Product ID EOC
LRH1070/00 SENSR SURFACE BOX 731438 99
51.5
95
LRH1070
Extension cable for Wieland
connection of Occuswitch (LRM1070,
LRM1080)
Product ID EOC
LCC1070/00 PIR T-CABLE 3P 731773 99
113.5
26.5
1000
67.5
LCC1070
Wieland cable is available for easy, fast
and trouble-free installation. Same
as the LRM1070 but with parallel
operation (up to 10 Occuswitches),
local override and absence mode
