USB SECTION
USB Port
USB Standard USB 2.0 full speed
Supported media fi le format
MP3 ( ✱ .mp3)
WMA ( ✱ .wma)
JPEG ( ✱ .Jpg, ✱ .JPEG)
MPEG4 ( ✱ .asf)
USB device fi le system
FAT12
FAT16
FAT32
USB port power 500 mA (Max)
SPEAKER SECTION
Front speakers SB-HF250
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3
Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 87 Hz to 25 kHz (–16 dB)
98 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 252 mm x 1123 mm x 234 mm
Mass 3.7 k g
Surround speakers SB-HS250
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3
Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 96 Hz to 25 kHz (–16 dB)
120 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 92 mm x 135 mm x 95.4 mm
Mass 0.75 k g
Center speakers SB-HC250
Type 2 way, 2 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3
1. Full range 6.5 cm Cone type
2. Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 81 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 105 Hz to 25 kHz (–16 dB)
125 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 270 mm x 92 mm x 95.4 mm
Mass 1.25 k g
Subwoofer SB-HW250
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3
Woofer 16 cm Cone type
Input power (IEC) 125 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 32 Hz to 220 Hz (–16 dB)
38 Hz to 180 Hz (–10 dB)
Dimensions (W x H x D) 183 mm x 396 mm x 267 mm
Mass 4 k g
GENERAL
Power supply
For Continental Europe AC 230 V, 50 Hz
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
AC 110 to 127 V, 220 to 240 V, 50/60 Hz
Power consumption
Main unit
For Continental Europe
125 W
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
135 W
Dimensions (W x H x D) 430 mm x 60 mm x 363 mm
Mass Main unit 3.5 k g
Operating temperature range +5 °C to +35 °C
Operating humidity range
5 % to 90 % RH (no condensation)
Power consumption in standby mode approx. 0.8 W
* Rating with low-cut fi lter equipped amplifi er
Note
1. Specifi cations are subject to change without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Maintenance
Clean this unit with a soft, dry cloth.
– Never use alcohol, paint thinner or benzine to clean this unit.
– Before using chemically treated cloth, carefully read the instructions that came with the cloth.
– Do not use commercially available lens cleaners as they may cause malfunction. (Cleaning the lens is generally not
necessary although this depends on the operating environment.)
Specifi cations (continued)
