39
RQT8043
RQTX0055
ENGLISH
REFERENCE
Specifi cations
AMPLIFIER SECTION
For Continental Europe
RMS Output Power: Dolby Digital Mode
Front Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Surround Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Center Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Subwoofer Ch
125 W per channel (3 ), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 750 W
DIN Output Power: Dolby Digital Mode
Front Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Surround Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Center Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Subwoofer Ch
75 W per channel (3 ), 100 Hz, 1 % THD
Total DIN Dolby Digital mode power 450 W
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
RMS Output Power: Dolby Digital Mode
Front Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Surround Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Center Ch 125 W per channel (3 ), 1 kHz, 10 % THD
Subwoofer Ch
125 W per channel (3 ), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 750 W
PMPO output power 5600 W
DIN Output Power: Dolby Digital Mode
Front Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Surround Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Center Ch 75 W per channel (3 ), 1 kHz, 1 % THD
Subwoofer Ch
75 W per channel (3 ), 100 Hz, 1 % THD
Total DIN Dolby Digital mode power 450 W
FM TUNER, TERMINALS SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range 87.50 to 108.00 MHz (50-kHz step)
Sensitivity 1.8 µV (IHF)
S/N 26 dB 1.4 µV
Antenna terminals 75 (unbalanced)
Phone jack
Terminal Stereo, 3.5 mm jack
Mic jack
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
Sensitivity 0.7 mV, 1.2 k
Terminal Mono, 6.3 mm jack (2 system)
Music Port (Front)
Sensitivity 100 mV, 1.4 k
Terminal Stereo, 3.5 mm jack
VIDEO SECTION
Video system PAL625/50, PAL525/60, NTSC
Composite video output
Output level 1 Vp-p (75 )
Terminal
For Continental Europe Scart jack (1 system)
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
Pin jack (1 system)
For Continental Europe
S-video output
Y output level 1 Vp-p (75 )
C output level PAL; 0.3 Vp-p (75 )
NTSC; 0.286 Vp-p (75 )
Terminal Scart jack (1 system)
Component video output
(NTSC: 480p/480i, PAL: 576p/576i)
Y output level 1 Vp-p (75 )
P
B
output level 0.7 Vp-p (75 )
P
R
output level 0.7 Vp-p (75 )
Terminal Pin jack (Y: green, P
B
: blue, P
R
: red) (1 system)
For Continental Europe
RGB video output
R output level 0.7 Vp-p (75 )
G output level 0.7 Vp-p (75 )
B output level 0.7 Vp-p (75 )
Terminal Scart jack (1 system)
DISC SECTION
Discs played (8 cm or 12 cm)
(1) DVD (DVD-Video, DivX
*6, *7 )
(2) DVD-RAM (DVD-VR, JPEG *4, *7 , MP3 *2, *7 , MPEG4 *5, *7 ,
DivX *6, *7 )
(3) DVD-R (DVD-Video, DVD-VR, JPEG *4, *7 , MP3 *2, *7 ,
MPEG4 *5, *7 , DivX *6, *7 )
(4) DVD-R DL (DVD-Video, DVD-VR)
(5) DVD-RW (DVD-Video, DVD-VR, JPEG
*4, *7 , MP3 *2, *7 ,
MPEG4 *5, *7 , DivX *6, *7 )
(6) +R/+RW (Video)
(7) +R DL (Video)
(8) CD, CD-R/RW (CD-DA, Video CD, SVCD
*1 , MP3 *2, *7 ,
WMA *3, *7 , JPEG *4, *7 , MPEG4 *5, *7 , DivX *6, *7 )
*1 Conforming to IEC62107
*2 MPEG-1 Layer 3, MPEG-2 Layer 3
*3 Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
*4 Exif Ver 2.1 JPEG Baseline fi les
Picture resolution: between 160 x 120 and 6144 x 4096
pixels (Sub sampling is 4:0:0, 4:2:0, 4:2:2 or 4:4:4).
Extremely long and narrow pictures may not be
displayed.
*5 MPEG4 data recorded with Panasonic SD multi cameras
or DVD video recorders
Conforming to SD VIDEO specifi cations (ASF standard)/
MPEG4 (Simple Profi le) video system/G.726 audio
system
*6 Plays all versions of DivX ® video (including DivX ® 6) with
standard playback of DivX ® media fi les. Certifi ed to the
DivX Home Theater Profi le.
*7 The total combined maximum number of recognizable
audio, picture and video contents and groups: 4000
audio, picture and video contents and 400 groups.
Pick up
Wavelength (DVD/CD) 662/785 nm
Laser power (DVD/CD) CLASS 1/CLASS 1M
NORSK
Bølgelengde (DVD/CD)
662/785 nm
Laserstyrke Ingen farlig stråling sendes ut
Audio output (Disc)
Number of channels 5.1ch (FL, FR, C, SL, SR, SW)
