14 Appendix
English
79
En
Specifications
Item 50"Plasma Display, Model: PRO-505PU 43" Plasma Display, Model: PRO-435PU
Number of Pixels 1280 × 768 pixels 1024 × 768 pixels
Audio Amplifier 13 W + 13 W (1 kHz, 10 %, 8 Ω) 13 W + 13 W (1 kHz, 10 %, 8 Ω)
Surround System SRS/FOCUS/TruBass SRS/FOCUS/TruBass
Power Requirement 120 V AC, 60 Hz, 363 W (0.2 W Standby) 120 V AC, 60 Hz, 298 W (0.2 W Standby)
Dimensions 1270 (W) × 737 (H) × 93 (D) mm 1120 (W) × 652 (H) × 93 (D) mm
(50 (W)
× 29 (H) × 3
11/16 (D) inches) (44 1/8 (W)
× 25
11/16 (H)
× 3
11/16 (D) inches)
Weight 32.8 kg (72.3 lbs.) 26.8 kg (59.1 lbs.)
Item Media Receiver, Model: PRO-R05U
Reception System (Digital) ATSC Digital TV system
Circuit type 8VSB/64QAM/256QAM/QPSK demodulation
Tuner VHF/UHF VHF 2–13ch, UHF 14–69ch
CATV 2–135ch
Audio format Dolby Digital
Reception System (Analog) American TV standard NTSC system
Circuit type Video signal detection PLL full synchronous detection, PLL digital synthesizer
system
Tuner VHF/UHF VHF 2–13ch, UHF 14–69ch
CATV ANTENNA/CABLE A IN: 1–135ch Cable: 1–125ch
Audio multiplex BTSC system
Terminals Rear ANTENNA/CABLE A IN 75
Ω UNBAL, F Type for DTV/VHF/UHF/CATV in
ANTENNA B 75 Ω UNBAL, F Type for VHF/UHF/CATV in
Loop out
i.LINK (TS) S400 (2)
INPUT 1 COMPONENT VIDEO in, S-VIDEO in, VIDEO in, AUDIO in, HDMI in
INPUT 2 S-VIDEO in, VIDEO in, AUDIO in
INPUT 3 COMPONENT VIDEO in, AUDIO in, HDMI in
Monitor Out S-VIDEO out, VIDEO out, AUDIO out
Digital Audio Output Optical (1)
VCR Control Output 1
CONTROL IN 1
CONTROL OUT 1
Cable CARD Point of Deployment
Front INPUT 4 COMPONENT VIDEO in, S-VIDEO in, VIDEO in, AUDIO in
PC Analog RGB in, AUDIO in
OSD English/French/Spanish
Power Requirement 120 V AC, 60 Hz, 43.3 W (31 W Standby)
Dimensions 420 (W) × 90 (H) × 295 (D) mm
(16 9/16 (W) × 3
9/16 (H) × 11
10/16 (D) inches)
Weight 5.8 kg (12.8 lbs.)
• Design and specifications are subject to change without notice.
