Installation Instructions
Table of Contents
THE WALL STRUCTURE MUST BE CAPABLE OF SUPPORTING AT LEAST FIVE TIMES THE WEIGHT OF THE DISPLAY. IF
NOT, THE WALL STRUCTURE MUST BE REINFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE
TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD
RESULT IN SERIOUS PERSONAL INJURY, OR EVEN DEATH. DO NOT USE THIS MOUNT WITH A DISPLAY WEIGHING IN
EXCESS OF 160LBS.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF THIS PRODUCT. USE PROPER
SAFETY GEAR AND TOOLS FOR THE INSTALLATION PROCEDURE TO PREVENT PERSONAL INJURY.
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND COM-
PLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND
PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE
REFERENCE.
Warning Statements
Indicates that the power plug is to be disconnected
from the power outlet.
Safety precautions must be taken at all times.
Warning and Caution statements.
Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to do so could result in damage to the flat panel
display and/or damage to the mounting surface.
Do not install near heater, fireplace, direct sunlight, air conditioning or any other source of direct heat energy. Failure to do so may result in
damage to the flat panel display and could increase the risk of fire.
At least two qualified people should perform the installation procedure. Injury and/or damage can result from dropping or mishandling the
flat panel display.
Contact Premier Mounts with any questions -
(800) 368-9700.
Warning
Statements
2
Parts
List 3
Installation
Tools
3
Thread
Depth
Indicator
6
Mount
Orientation 7
Securing
the
Mounting
Brackets
8
Marking
the
Wall
9
Lower
Mounting
Points
9
PCM-MS3
Installation
10
Securing
the
Display
11
Lateral
Shift
Adjustment
11
Safety
Knurl
Knob
Installation
11
Technical
Specififcations
12
Warranty 13
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT
FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACH-
MENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS, ACTIONS OR
CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY
SUCH USE, ATTACHMENTS OR MODIFICATIONS.
It is recommended that a maximum of 5/8” plaster board be used when mounting to wooden studs.
PCM-MS3
