– 145 –

MAIN Menu Screen 4 of 4 (SUB menus)

Sensitivity measurement screen

The settings for the sensitivity measurement are performed on this screen.

Item

SENSITIVITY

KNEE

W.CLIP

M.PED

VIDEO OUT

Variable

range

ON
OFF

ENC
Y
R
G
B

Remarks

This selects ON or OFF for the
sensitivity measurement.

This selects ON or OFF for KNEE.

This selects ON or OFF for W.CLIP.

This adjusts the master pedestal.

This switches the VIDEO OUT.

display

ENG

The underlining in the variable range column indicates the setting in the preset mode.

USER menu: The USER menu appears when the MENU switch is set to SET.
ENG menu:

The ENG menu appears when the MENU switch is set to SET while the SHIFT/ITEM button and UP button are
held down together.

E V A L U A T I ON

K N E E

W . C L I P
M . P E D

V I D E O OU T

:
:
:

:
: O F F

O F F

0 0

S E N S I T I V I T Y

{
