22
VF CONFIG
The underlined values are factory preset setting values.
Sub menu Settings Explanation
VF CONTROL VF-CH
ALL-CH Used to select the input line for the VF function of the monitor.
(VF function: tally lamp lit, zebra displayed, displayed)
Only enabled when the VF line is selected.
Enabled with all input lines.
CROSS HATCH HIGH
LOW
OFF Used to set whether to display a cross hatch and select its density
level.
70/256 (displays with a dense cross hatch)
20/256 (displays with a light cross hatch)
Not displayed.
REAR TALLY ON
OFF Used to allow control of the tally lamp on the rear of the monitor.
Lamp lights when TALLY control from a GPI/camera is ON.
Lamp does not light.
ZEBRA ON
OFF Used to set ZEBRA information in the camera.
Sets the information to ON.
Sets the information to OFF.
RETURN CH
∗1∗2 YP
B
P
R
VF
VIDEO
SDI
Used to select the signal input line by operating the RETURN (RET)
button of the camera lens.
When there is no SDI input unit (option), the SDI item is displayed in
gray and cannot be set.
• The priority sequence for GPI control and RS-232C is as follows: GPI > VF CONFIG > RS-232C.
∗1 RETURN CH operates when VF CONTROL is set to ALL-CH. It is not affected by the various line ON/OFF
settings in the INPUT SELECT menu (→ page 29). (Input lines that are set with RETURN CH are enabled even
if they are set to OFF in INPUT SELECT.)
∗2 A function to be used with future Panasonic camera-recorders.
Main Menu
(continued)
