Page 19
19
VIDEO CONFIG
The underlined values are factory preset setting values.
Sub menu
Settings
Explanation
COLOR TEMP.
USER 63∗
1
D93
D65
D56
VAR1
VAR2
VAR3
Used to select the color temperature.
(color temperature around 3000K - 9300K)
2
2
2
SHARPNESS
MODE
HIGH∗
3
LOW
Used to select the width of the sharpness edge.
SHARPNESS H
0 - 30∗
3
Used to set the sharpness in the horizontal direction.
When adjusting, the item display moves to the lower part of the
screen.
SHARPNESS V
0 - 30∗
3
Used to set the sharpness in the vertical direction.
When adjusting, the item display moves to the lower part of the
screen.
I-P MODE
MODE2
MODE1
Used to select IP conversion mode. (→ page 20 “About IP Mode”)
MONO∗
4
OFF
ON
Used to switch between color and monochrome (MONO).
∗ When this is ON, the picture adjusting knob [CHROMA] setting is
fixed at 0.
SD ASPECT∗
4
4:3
16:9
Used for setting the aspect ratio settings when using SD signal
input.
<4:3> 4:3 display <16:9> 16:9 display
∗1 When selecting USER 0 - 63
1) Push [ENTER] (USER changes to blue). 2) Select 0 - 63 with [
,
], and push [ENTER].
∗2 When “VAR1”, “VAR2” or “VAR3” is selected, the monitor switches to WB adjustment mode (→ page 20).
∗3 The following sharpness values can each be set,
1) VIDEO system input line (VIDEO)(Factory settings are SHARPNESS MODE: LOW, SHARPNESS H/V: 0)
2) any other input line’s HD (Factory settings are SHARPNESS MODE: HIGH, SHARPNESS H/V: 0)
3) any other input line’s SD (Factory settings are SHARPNESS MODE: LOW, SHARPNESS H/V: 0)
and the setting values for the selected input signal from within this group is displayed. The adjustment status is
displayed in the bottom right when selected.
∗4 During GPI control, the setting items are displayed in gray and the display changes in accordance with the GPI
control.
Main Menu
(continued)
