Panasonic BT-LH80WP - Manual (Page 21)

21
SYSTEM CONFIG
The underlined values are factory preset setting values.
Sub menu Settings Explanation
CONT. /BACK. BACKLIGHT
CONTRAST Used to select the function to be assigned to CONT/B.LIGHT (a knob
on the front panel).
Used to adjust BACKLIGHT.
Used to adjust CONTRAST.
BACKLIGHT 0 - 60 Used to adjust the LCD backlight level.
CONT./BACK displays “-” while BACKLIGHT settings are performed.
PEAKING/PHASE PEAKING
PHASE Used to select the function to be assigned to PEAK/PHASE (a knob
on the front panel).
Assigns to the PEAKING function.
Assigns to the PHASE function.
STATUS DISPLAY CONTINUE
3SEC OFF∗
1
OFF
Used to set the display time for the status display.
Always displayed.
<3SEC OFF> Displayed for 3 seconds.
Not displayed.
BATTERY REMAIN OFF
ON Used to select whether or not to display the battery level.
Not displayed.
Displayed.
SETUP LOAD FACTORY
USER1
USER2
USER3
USER4
USER5 Used to load the saved factory preset setting values (FACTORY) or
user data (USER 1 - USER 5).
The factory preset settings.
The saved USER data ∗
2 .
When the unit is shipped from the factory, the USER 1 to 5 data items
are the same as the factory preset values.
SETUP SAVE USER1
USER2
USER3
USER4
USER5 Used to save user data.
Up to 5 sets of user data can be saved, which include the current
setting values for the menu and picture adjusting knobs.
PWR ON SETUP LAST
FACTORY
USER1
USER2
USER3
USER4
USER5 Used to select the settings for when the power supply is switched
ON.
Starts up with same settings as the last time the power
supply was switched OFF.
Starts up with the FACTORY settings.
Starts up with the settings that are saved in a USER
item.
∗1 Functions as CONTINUE when (warning of improper operation status for the camera settings) is displayed
or when the P-P (PIXEL TO PIXEL) status is displayed.
∗2 USER saving is not possible when CONTROL is set to REMOTE.
Main Menu
(continued)
