Appendix 1
Appendix 1 - Detailed Specifications of VersaCam IC-360
1. General
CPU
32bit RISC Embedded processor
Flash memory
8Mbyte
RAM
16Mbyte
OS
Embedded Linux
Video Channel
NTSC or PAL video formats are supported
1 Channel of External Video Output
Image Resolution Control
720x486, 720x243, 360x243, 180x121, 90x60 pixels
Image Compression
Wavelet
Compression Rate
10:1 ~200:1
Transfer Rate
Max 120 fps ([4.7KB image] up to 30 fps, 1 - 4 clients)
Decoding Rate
2 ~ 30fps (depends on client system)
Compression rate
Max 30 fps
Security
Password-Based User Authentication
IP-filtering (Secure Mode)
Image Encryption
Alarms and I/O
Motion detection
Software-controlled dual (2) alarm inputs
Sending E-mail automatically
Sending image files through FTP automatically
Misc. functions
High quality image area setting
Image compression control (10 Levels)
Periodic sending of images through E-mail, FTP
Gray/Progressive/Single-Shot Mode
User-customized home page publishing supported by FTP
Power Supply
DC 12V, 3.5A via external power supply supplied
Sensor input
2 auxiliary inputs are supported
2. CCD Camera
Image Sensor
1/4-inch color interline-transfer CCD
Total Pixels
410,000 pixels NTSC-811(H) x 508(V), PAL-795(H) x 596(V)
Active Pixels
380,000 pixels 768(H) x 494(V), PAL-752(H) x 582(V)
Scanning Frequency
15.734kHz (H) 59.94Hz(V)
Synchronization
Internal/External (AC Line Lock)
Video Output
1.0 Vp-p/75 ohm
Interface
RS232, BNC (Video)
Resolution
480/440 TV Lines (Slow Shutter Mode)
S/N Ratio
More than 50dB
White Balance
Automatic Tracing White Balance (ATW)/AWC
Back Light Compensation
Super BLC/BLC/ Wide Dynamic Range/Off
Focus
Auto/Manual
Electronic Shutter
Auto/Manual (1/60 to 1/10,000 12 steps)
Slow Shutter
Auto (1/30 to 1/2)/OFF
Flickerless
Auto/Manual (Fixed 1/100)
lris
Automatic
Gain Control
Automatic
