26
USB
Compatibility: Hi-Speed USB (2.0) •
Class support: UMS (USB Mass Storage Class) •
Main unit
Power supply rating: 110~240V ~AC, 50/60 Hz •
Power consumption: 22W •
Power consumption in standby mode: < 0.25 W •
Dimensions (w x h x d): 435 x 55.7 x 245 (mm) •
Net Weight: 2.4 kg •
Accessories supplied
Remote control and batteries •
HDMI cable •
Audio/Video cables •
Power cable •
Quick start guide •
User manual •
Optional accessory
A wireless Philips USB adapter(named •
WUB1110, sold separately)
Multimedia connections: Wi-Fi •
802.11b/g/n
Connectivity: Rear connection (USB)
•
Ambient temperature: 5 deg C to •
40 deg C.
Dongle dimensions (W x H x D):
•
28.4 x 82 x 13.4 mm
Laser Specification
Laser Type: •
BD Laser Diode: AlGaInN •
DVD Laser Diode: AlGaInP •
CD Laser Diode: AlGaInP •
Wave length:
•
BD: 405 +5nm/-5nm •
DVD: 655 +10nm/-10nm •
CD: 790 +10nm/-20nm •
Output power:
•
BD: Max. ratings: 20mW •
DVD: Max. ratings: 6mW •
CD: Max. ratings: 7mW •
Note
Do not turn off the power or remove the USB flash •
drive when software updating is in progress to prevent
possible damage of this product.
Care
Caution
Never use solvents such as benzene, thinner, cleaners •
available commercially, or anti-static sprays intended
for discs.
Clean discs
Wipe the disc with a micro fibre cleaning cloth from
the centre to the edge in a straight line movement.
Specifications
Note
Specifications are subject to change without notice •
Video
Signal system: PAL / NTSC •
Composite video output: 1 Vp-p (75 ohm) •
Component video output: 480/576i, 480/576p, •
720p, 1080i
Y: 1 Vp-p (75 ohm) •
Pb: 0.7 V-pp (75 ohm) •
Pr: 0.7 V-pp (75 ohm) •
HDMI output 480p, 576p, 720p, 1080i, 1080p,
•
1080p24
Audio
2 Channel analog output •
Audio Front L + R : 2 Vrms (> 1 kohm) •
Signal to noise ratio: > 120 dB •
Dynamic Range (1kHz): >100 dB •
Total harmonic distortion: <90 dB •
7.1 Channel analog output
•
Audio Front L + R : 2 Vrms (> 1 kohm) •
Audio Surrond L + R : 2 Vrms (> 1 •
kohm)
Audio Center : 2 Vrms (> 1 kohm)
•
Audio Subwoofer : 1.15 Vrms (> 1 kohm) •
Audio Rear L + R: 2 Vrms (> 1 kohm) •
Digital output: 0.5 Vp-p (75 ohm)
•
Optical, Coaxial •
HDMI output
•
