I V . T H E J A Z Z Y 1 1 0 4

SPECIFICATIONS

Suspension:

Limited suspension

Drive Wheels:

14 in., pneumatic (solid tires are optional)

Rear Casters:

8 in., solid, rear articulating

Anti-tip:

6 in., solid, front mounted

Maximum Speed: Up to 4.5 mph
Brakes:

Intelligent Braking, electronic regenerative, disc park brake

Ground Clearance: 3.5 in.
Turning Radius:

19.5 in.

Overall Size:

Length: 39.5 in.
Width: 25.4 in.

Seating Options:

Medium-back
High-back with headrest

Drive Train:

Two motor, mid wheel

Batteries:

Two 12-volt, Group 24 batteries

Range:

Up to 25 miles

Battery Charger:

Onboard
Off-board (optional)

Electronics:

50-amp P & G Pilot Controller

Weight Capacity:

250 lbs.

Jazzy Weights:

Base: 81 lbs.
Seat: 29 lbs.
Batteries: 48 lbs.

Warranty:

Lifetime limited warranty on frame
Two-year warranty on electronics
Eighteen-month warranty on drive motor
