6

www.pridemobility.com

Jazzy Select 14 Series

I I . S A F E T Y

Removal of grounding prong can create electrical hazard. If necessary, properly install

an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.

Place unit on level ground and stand to one side when changing from drive mode to

freewheel mode or freewheel mode to drive mode.

Battery Set Configuration:

+ = Positive (Red) Terminal Post

– = Negative (Black) Terminal Post

Connect Red wires to Red Positive (+) Terminal Posts

Connect Black wires to Black Negative (–) Terminal Posts

EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.

Unlocked and in freewheel mode.

Locked and in drive mode.

Do not place power chair in freewheel mode on a decline.

Do not place power chair in freewheel mode on an incline.
