Jazzy Select 14 Series

www.pridemobility.com

39

A P P E N D I X I - S P E C I F I C A T I O N S

Suspension: Limited

Drive Wheels:

14 in. (35.56 cm) solid or pneumatic, center-mounted

Caster Wheels:

8 in. (20.32 cm) solid, rear articulating

Anti-tip Wheels:

6 in. (15.24 cm) solid, front mounted

Maximum Speed:

1

Jazzy Select 14: Up to 4.5 mph (7.24 km/h)
Jazzy Select 14XL: Up to 4 mph (6.5 km/h)

Range:

1,4

Variable up to 10 miles (16 km)

Brakes: “Intelligent

Braking”

electronic regenerative, disc park brake

Ground Clearance:

2

See figure 23.

Turning Radius:

2

See figure 23.

Overall Size:

2

Length: See figure 23.

Width: See figure 23.

Drivetrain:

Two motor, mid-wheel

Batteries:

3

Two 12-volt, deep-cycle NF-22 batteries

Battery Charger:

5-amp off-board

Weight Capacity:

Jazzy Select 14: 300 lbs. (136 kg)

Jazzy Select 14XL: 400 lbs. (181 kg)

Component Weights:

2

Jazzy Select 14 Base: 105 lbs. (47.63 kg)

Jazzy Select 14XL Base: 106.5 lbs. (48.3 kg)

Batteries: 38 lbs. (17.23 kg) each

1

Varies with base model, user weight, terrain type, battery amp hour rating (Ah), battery charge, battery
condition, motors, controller type, tire type, and tire condition. This specification can be subject to a variance of
(+ or -) 10%.

2

Due to manufacturing tolerances and continued product improvement, this specification can be subject to
variance of (+ or – ) 3%.

3

AGM or Gel-Cell type required. See IV. “Batteries and Charging.”

4

Tested in accordance with ASNI/RESNA, WC Vol 2, Section 4 & ISO 7176-4 standards. Results derived from
theoretical calculation based on battery specifications and drive system performance. Test conducted at maxi-
mum weight capacity.

NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO EN 12184 stan-

dards. All specifications subject to change without notice.

SPECIFICATIONS
