6
2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product. This
product has been thoroughly inspected and tested and is warranted for
One Year parts and labor. If any questions or problems arise during
installation or use of this product, please do not hesitate to contact
Patton Electronics Technical Support at (301) 975-1007 .
2.1 FEATURES
• 64 kbps synchronous data rate
• Provides 64K co-directional interface compliant with G.703 electrical
specs.
• Offers a single Tx/Rx interface with a standard RJ45 connector as
specified in TBR14.
• Point-to-point distances up to 5 miles (all data rates) on 24 AWG
twisted pair
• Up to 1 mile (1.6 km) additional distance on G.703 line.
• Remote digital loopback, local line loopback diagnostic modes
• Full duplex operation over a single twisted pair (2-wires)
• Able to work in clear channel or Octet timing modes*
• Complies with ITU/CCITT G.823 (control of jitter).
• Compatible with popular Patton Models 1092A, 1092ARC, 3092, and
3192
• SNMP manageable as the remote CPE when used with Patton’s other
SNMP-manageble products
• Universal power options, 120 VAC, 230 VAC and -48 VDC are available
• Front panel status indicators
• Small, convenient desktop unit
• CE marked
2.2 DESCRIPTION
The Patton Model 1082/F is a high speed, AC powered short range
modem that is able to convert data from a 64K G.703 network and trans-
mit it at extended distances via 2 wire (single twisted pair) DSL. The
G.703 network provides a 64K co-directional three level signal using
either octet timing or clear channel mode. The 1082/F will detect and
pass either octet timing (preserving byte integrity over the modem link) or
* Octet timing mode available when used in 1082/F-to-1082/F config-
urations only.
