COMSPHERE 3825Plus Modem
C-2
January 1999
3825-A2-GB30-40
Table C-1
(2 of 2)
Model 3825
Plus Technical Specifications
Specifications
Description
ENVIRONMENT
Operating Temperature
Relative Humidity
Shock and Vibration
Storage Temperature
32
°
F (0
°
C) to 122
°
F (50
°
C)
5% to 90% (noncondensing)
Withstands normal shipping
– 4
°
F (– 20
°
C) to 158
°
F (70
°
C)
DTE INTERFACE
25-pin D-subminiature
connector
EIA-232-E/ITU-T V.24
AC POWER
REQUIREMENTS
100 Vac
±
10%, 50/60 Hz;
115 Vac
±
10%, 60 Hz;
220 Vac
±
10%, 50 Hz; or
240 Vac
±
10%, 50 Hz
POWER CONSUMPTION
6 watts (typical, including power transformer, speaker off)
DIMENSIONS
Weight
Height
Width
Depth
1.3 pounds (0.59 kg) (not including power transformer)
1.25 inches (3.0 cm)
6.0 inches (15 cm)
8.75 inches (22 cm)
TRANSMIT LEVEL
Dial Line
Leased Line
Permissive (–9 dBm through –32 dBm in 1-dBm increments)
0 through –15 dBm in 1-dBm decrements
VOICE FREQUENCY
LINE REQUIREMENTS
2-wire dial (PSTN) or 2-wire leased line
PSTN INTERFACE
RJ11C Permissive
RJ14C (if connecting a two-line telephone)
PRIVATE LINE
INTERFACE
Single line JM8 using adapter cable
