COMSPHERE 3825Plus Modem
4-6
January 1999
3825-A2-GB30-40
Table 4-1
(4 of 14)
3825
Plus AT Commands
Q
n
Result Codes
Result codes are informational messages (such as Connect and Ring) sent from the modem and displayed on the
asynchronous DTE terminal. Refer to Table A-1 for a list of result codes.
Q, Q0
Enables modem to send result codes to the DTE.
Q1
Disables modem from sending result codes to the DTE.
Q2
Enables in Originate mode only for modem to send result codes to the DTE. Required for most
UNIX applications.
S
n =r
Change S-Register
Changes the contents of an S-register, where
n is the S-register, and r is the new value.
S
n?
Display S-Register
Displays the value of an S-register, where
n is the S-register number.
T
Tone Dial
Sets the modem for Tone (DTMF) dial mode. See D command.
V
n
Result Codes Format
Controls whether or not result codes appear as words or as numeric codes. Some DTEs do not recognize result codes as
words; therefore, numbers are required. The Numbers (2) format is required for some modem pooling applications. Refer
to Table A-1 for a list of result codes.
V, V0
Displays result codes in Number (1) format (digits).
V1
Displays result codes as text.
V2
Displays result codes in Number (2) format (digits).
X
n
Extended Result Code, Dial Tone Detect, and Busy Tone Detect
The X
n command sets three configuration options simultaneously:
Extended Dial Tone Busy Tone
Result Code Detect Detect
X0
Disable
Disable Disable
X1
Enable
Disable Disable
X2
Enable
Enable Disable
X3
Enable
Disable Enable
X4
Enable
Enable Enable
X5
Add/EC
Enable Enable
X6
Add/V42,MNP
Enable Enable
X7
Use DTE Rate
Enable Enable
EXTENDED RESULT CODE
Informational messages such as VF (line) connect rate and Error Control are displayed with the result codes.
Disable.
Displays basic result codes: OK, CONNECT, RING, NO CARRIER, and ERROR.
Enable.
Displays basic result codes in addition to the CONNECT rate message (for example, CONNECT 14400).
