Index
Index-3 3825-A2-GB30-40 January 1999
escape sequence (+++), 4-1, 4-17
ETC (Enhanced Throughput Cellular), 4-10, 4-26
&F Factory Defaults, 4-9
&I Dial Transmit Level, 4-10
\N Error Control Mode, 4-15
Cellular Enhancement, 4-26
RJ11 Cellular Adapt, 4-26
extended result codes (ATX), 4-6
F
Fast Disconnect, 4-25
fax
+FCLASS command, 4-14
operation, 3-1
problems and solutions, B-5
software settings, 3-1
standards, 3-1
types supported, 1-1
features, 1-1
firmware cloning, 4-8
firmware download, B-5
firmware revision number, 4-5
firmware upgrade, B-5
flow control
AT\Q command, 4-15
DTE to modem, 4-15
modem to DTE, 4-15
modem to modem, 4-14
problems, B-2
frame size (\A), 4-14
front panel, 1-2
front panel LEDs, 1-2
H
hang up (ATH), 4-5
hook flash, 4-4
Hook Switch Control (ATH), 4-5
I
Identification (ATI), 4-5
indicator lights, 1-2
initialization strings, 2-6
DATAKIT, 2-6
synchronous leased-line applications, 2-6
V.25bis applications, 2-6
installation
3825Plus modem, 2-2
software, 2-3
ITU-T/Bell Mode (B command), 4-3
J
JM8 to RJ11 crossover cable, 2-3, D-2
L
Leased Line Carrier On Level (S48), 4-21
Leased Line Rate, 4-21
Leased Line Transmit Level (S45), 4-21
Leased Mode (AT&L), 4-10
leased-line connection, 2-3
leased-line problems, B-2
LEDs (front panel), 1-2
Line Current Disconnect (S65), 4-23
load Active (Operating) area, 4-7
LSD Control (AT&C), 4-8
M
menu tree, remote, 5-2
MNP5 Data Compression (AT%C), 4-14
modulation problems, B-3
Modulation/Data Rate (%B), 4-13
modulations supported, C-1
N
network management system (NMS), 1-2
NMS (COMSPHERE 6700 or 6800 Series NMS), 1-2
No Carrier Disconnect (S10), 4-18
No Data Disconnect Trigger Signal, 4-25
O
operating modes, 4-1
Originate Security (S70), 4-30
P
P (Pulse dial), 4-4
part numbers, 2-1
password
Administration, 4-27
deletion (%SP=), 4-29
display (%SP), 4-29
DTE (%SD), 4-29
entry attempt limit, 4-30
entry wait time, 4-30
Originate Access, 4-27
Remote Access, 4-22
types, 4-27
VF (%SV), 4-29
VF plus DTE (%SB), 4-29
VF Prompt Type, 4-30
pin assignments
EIA-232-E, D-1
JM8 to RJ11 crossover cable, D-2
Power LED, B-1
power-up procedure, 2-4
primary channel, 5-1
