Cables and accessories

Miscellaneous

Part Number

Cable, DVI-VGA, 3 m, white, smooth surface

903-0228-00

Cable, DVI-VGA, 3 m, black, smooth surface

903-0229-00

Cable, DVI-VGA, 10 m, white, smooth surface

903-0230-00

Cable, DVI-DVI, 3 m, white, smooth surface

903-0231-00

Cable, DVI-DVI, 10 m, white, smooth surface

903-0232-00

European medical grade power cord, 3 m

903-0251-00

US medical grade power cord, 3 m

903-0169-00

Touchscreen cable, 3 m, white, smooth surface

903-0234-00

Touchscreen cable, 10 m, white, smooth surface

903-0235-00

Universal mounting plate

501-0301-00

Planar desk stand

501-0348-00
