Onscreen Display Lockout
The display incorporates an OSD lockout function. Pressing controls
Function DOWN, Adjust PLUS, and Adjust MINUS—that is, buttons 2, 3, and 4—
simultaneously lock out the onscreen display. Display settings cannot be altered at
this point, but navigation through the OSD menus is possible. An “OSD” lock
appears at the bottom of the OSD menu. To unlock the onscreen display, press the
same three controls in the same manner as if locking the display.
